Stop Adding Secrets to Your mcp.json: Adding OAuth to Remote MCP Servers with Authelia

If you’ve used MCP servers with Cursor, Claude Code, or any other AI coding tool, then you’ve seen this before. You find a cool MCP server, you set it up, and then you paste an API key or token straight into your mcp.json or maybe you get to put it in an environment variable.

I’ve been revamping my entire homelab setup recently, migrating from old Portainer-managed Docker containers to a proper CI/CD pipeline with Kubernetes. The kind of project where you start with “this will take a weekend” and three weeks later you’re writing Terraform for your DNS server. I’m planning to write about the full overhaul separately, but this post is about one specific container that wasn’t the lowest hanging fruit.

At this point I had already migrated a fair share of containers to helm charts and was applying them locally when I stumbled across the Prometheus MCP server that I once setup. I liked it a lot. But I had recently put Authelia in front of Prometheus’s web UI, and it wouldn’t make much sense to expose an MCP server with zero authentication while Prometheus itself sits behind SSO.

The question was: how do you add auth to an MCP server without just adding another secret to mcp.json?

The Atlassian Experience: How It Should Work

Then I remembered the Atlassian MCP server. In case you haven’t used it, here’s the entire Cursor config:

{
    "mcpServers": {
        "atlassian": {
            "command": "npx",
            "args": ["-y", "mcp-remote", "https://mcp.atlassian.com/v1/sse"]
        }
    }
}

With this being the entire config for it. When Cursor connects, mcp-remote opens your browser, you log into Atlassian, approve the connection, and it redirects back to localhost. The token is handled entirely by the OAuth flow and stored by mcp-remote.

So this has got me thinking: I have an OIDC provider now and I do have an MCP server. How hard could it be to wire them together?

If you’ve read any of my blog posts then you can probably guess what comes next. This was actually one of the reasons why I wanted my homelab checked into a repository because it means I can now run Cursor on it.

The Idea: An OIDC Gateway for Any MCP Server

Most MCP servers don’t know about OAuth. They are simple HTTP servers that accept requests and return tool results. They don’t know about tokens, authorization codes, or PKCE flows.

But mcp-remote, the npm package that bridges stdio-based MCP clients to remote HTTP servers, does speak OAuth. It knows how to:

1. Fetch OAuth discovery metadata from /.well-known/ endpoints
2. Open a browser for the user to authenticate
3. Handle the redirect callback
4. Attach Bearer tokens to subsequent requests

So the idea was somewhat simple: put a thin nginx layer in front of your MCP server that does three things:

• Serves OAuth discovery metadata that tells mcp-remote where to find your OIDC provider’s authorization and token endpoints
• Validates Bearer tokens by checking each request’s token against your OIDC provider’s userinfo endpoint
• Proxies authenticated requests by forwarding valid requests to the actual MCP server

Your MCP server stays dumb and happy. Nginx handles the OAuth process. And from the client side, it looks exactly like the Atlassian experience: just a URL, no secrets.

The best part? This pattern works with any OIDC provider. If it speaks OIDC, then you can connect it.

Here’s what the full flow looks like end to end:

The Implementation

I built this in a single pair-programming session with Opus 4.6 for the planning, Sonnet 4.5 for the implementation. About 60 minutes wall clock time.

The OAuth Gateway (nginx ConfigMap)

This is the centerpiece. nginx serves three /.well-known/ documents as static JSON and uses auth_request to validate tokens:

data:
    nginx.conf: |
        worker_processes auto;
        error_log /dev/stderr warn;
        pid /var/run/nginx.pid;
        events {
            worker_connections 1024;
        }
        http {
            include /etc/nginx/mime.types;
            default_type application/octet-stream;
            log_format main '$remote_addr - $remote_user [$time_local] "$request" '
                            '$status $body_bytes_sent "$http_referer" '
                            '"$http_user_agent" "$http_x_forwarded_for"';
            access_log /dev/stdout main;
            sendfile on;
            keepalive_timeout 65;

            server {
                listen 8080;
                server_name _;

                # Serve OAuth discovery metadata as static JSON
                location /.well-known/ {
                    root /etc/nginx/metadata;
                    default_type application/json;
                    add_header Cache-Control "no-cache, no-store, must-revalidate";
                }

                # Internal: validate Bearer token via Authelia's userinfo endpoint
                location = /auth-validate {
                    internal;
                    proxy_pass https://sso.internal.sunbury.xyz/api/oidc/userinfo;
                    proxy_pass_request_body off;
                    proxy_set_header Content-Length "";
                    proxy_set_header Authorization $http_authorization;
                }

                # Main proxy: authenticate then forward to MCP server
                location / {
                    auth_request /auth-validate;
                    error_page 401 = @unauthorized;

                    proxy_pass http://localhost:8000;
                    proxy_http_version 1.1;
                    proxy_set_header Host $host;
                    proxy_set_header X-Real-IP $remote_addr;
                    proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
                    proxy_set_header X-Forwarded-Proto $scheme;
                    proxy_buffering off;
                    proxy_cache off;
                }

                # Return proper WWW-Authenticate header for unauthorized requests
                location @unauthorized {
                    add_header WWW-Authenticate 'Bearer realm="Prometheus MCP"' always;
                    add_header Content-Type 'application/json' always;
                    return 401 '{"error":"unauthorized","error_description":"Bearer token required"}';
                }
            }
        }

The @unauthorized handler is important because it returns the WWW-Authenticate: Bearer header that tells mcp-remote “you need to do an OAuth flow.”

Then the OAuth discovery documents that mcp-remote fetches to figure out where to send the user for authentication:

oauth-authorization-server: |
    {
      "issuer": "https://sso.internal.sunbury.xyz",
      "authorization_endpoint": "https://sso.internal.sunbury.xyz/api/oidc/authorization",
      "token_endpoint": "https://sso.internal.sunbury.xyz/api/oidc/token",
      "userinfo_endpoint": "https://sso.internal.sunbury.xyz/api/oidc/userinfo",
      "jwks_uri": "https://sso.internal.sunbury.xyz/jwks.json",
      "response_types_supported": ["code"],
      "grant_types_supported": ["authorization_code"],
      "code_challenge_methods_supported": ["S256"],
      "token_endpoint_auth_methods_supported": ["none", "client_secret_basic", "client_secret_post"]
    }
oauth-protected-resource: |
    {
      "resource": "https://prometheus-mcp.internal.sunbury.xyz",
      "authorization_servers": ["https://sso.internal.sunbury.xyz"]
    }

These are just static JSON files that nginx serves from disk. No logic, no templating at runtime. mcp-remote reads them and knows: “Ah, to talk to this MCP server, I need to authenticate via Authelia at sso.internal.sunbury.xyz.”

The Two-Container Deployment

The MCP server itself and the nginx gateway run as a sidecar pair in the same pod:

containers:
    - name: nginx
      image: 'nginx:1.27-alpine'
      securityContext:
          allowPrivilegeEscalation: false
          capabilities:
              drop:
                  - ALL
          readOnlyRootFilesystem: true
      ports:
          - name: http
            containerPort: 8080
      # ... volume mounts for config and metadata

    - name: mcp-server
      image: ghcr.io/pab1it0/prometheus-mcp-server:latest
      env:
          - name: PROMETHEUS_URL
            value: 'http://prometheus.prometheus.svc.cluster.local:9090'
          - name: PROMETHEUS_MCP_SERVER_TRANSPORT
            value: 'http'
          - name: PROMETHEUS_MCP_BIND_HOST
            value: '0.0.0.0'
          - name: PROMETHEUS_MCP_BIND_PORT
            value: '8000'
      startupProbe:
          tcpSocket:
              port: mcp
          initialDelaySeconds: 10
          periodSeconds: 5
          failureThreshold: 60

nginx listens on 8080 (non-privileged, rootless), the MCP server listens on 8000. They talk over localhost. The security context is tight: runAsUser: 65534 (nobody), all capabilities dropped, read-only root filesystem on nginx. The startup probe gives the MCP server 5 minutes to get ready, which it needs because the container installs pip dependencies on boot.

The Authelia OIDC Client

On the Authelia side, this is registered as a public client with no client secret. Because mcp-remote runs on your local machine, it can’t securely store a secret anyway. Instead, it uses PKCE (Proof Key for Code Exchange) with S256:

• Client ID: prometheus-mcp
• Redirect URI: http://127.0.0.1/oauth/callback
• Scopes: openid profile email
• Grant type: authorization_code
• PKCE: Required, S256

The Payoff: The Cursor Config

And here’s what your mcp.json looks like at the end:

{
    "mcpServers": {
        "prometheus": {
            "command": "npx",
            "args": [
                "-y",
                "mcp-remote",
                "https://prometheus-mcp.internal.sunbury.xyz/mcp",
                "--host",
                "127.0.0.1",
                "--static-oauth-client-info",
                "{\"client_id\":\"prometheus-mcp\"}",
                "--transport",
                "http-only"
            ]
        }
    }
}

No API keys. No tokens. No secrets. Just a URL and a client ID. When Cursor connects, your browser opens Authelia’s SSO page. You log in (or you’re already logged in), approve, and you’re back. Exactly like the Atlassian experience.

The Gotchas

This went smoother than my last infrastructure adventure, but there were still a few bumps worth calling out.

Don’t forget DNS. This sounds obvious, but when you’re creating a new subdomain for an internal service, someone has to add the DNS entry. In my case, the agent forgot to add the Unbound alias and mcp-remote just threw ENOTFOUND errors. The fix was one small Terraform block:

resource "opnsense_unbound_host_alias" "prometheus_mcp_internal_sunbury_xyz_alias" {
  override = opnsense_unbound_host_override.k3s_1_svc.id
  enabled  = true
  hostname = "prometheus-mcp.internal"
  domain   = "sunbury.xyz"
}

Use 127.0.0.1 for the redirect URI. Pass --host 127.0.0.1 to mcp-remote and register http://127.0.0.1/oauth/callback in Authelia. Authelia’s loopback exception ignores the port during validation, so mcp-remote can use any available port.

The resource field must point to YOUR server. In the oauth-protected-resource discovery document, the resource field has to be the URL of your MCP server, not the OIDC provider’s issuer URL. The resource is what you’re protecting, not who’s doing the protecting.

SSE is deprecated. Use HTTP transport. I initially built this with SSE (Server-Sent Events) transport because that’s what the MCP server image defaulted to. The migration was a one-line change: PROMETHEUS_MCP_SERVER_TRANSPORT from "sse" to "http", and the URL in the Cursor config uses /mcp as the endpoint. Pass --transport http-only to mcp-remote to make sure it uses the streamable HTTP transport and doesn’t try to fall back to SSE.

Next Steps

What I’ve built here is binary auth: you’re either authenticated or you’re not. The MCP server doesn’t know or care who you are. It just knows someone with a valid Authelia session is asking for Prometheus data.

But the real power of OAuth in front of MCP servers is per-user scoping. Imagine a Confluence MCP server behind Keycloak where the server receives the authenticated user’s identity and only returns pages that you have access to. Or a GitHub MCP server that scopes its responses to your repositories. Or an internal documentation server that respects team boundaries.

That’s the next step. This will also be of interest to us at TNG. I have previously written my own MCP server to be able to talk to Confluence. Now with this TNG might be able to run the MCP server remotely and everyone just uses Keycloak to sign in.

There’s also the question of ergonomics. Right now, the --static-oauth-client-info flag and the mcp-remote wrapper are necessary because Cursor doesn’t natively handle OAuth for arbitrary MCP servers. But that’s changing. Atlassian’s MCP server already uses Cursor’s built-in auth support. No mcp-remote needed, just a URL. For self-hosted setups like mine, the missing piece is dynamic client registration (RFC 7591). Instead of manually registering a client ID in Authelia, the MCP client would register itself on the fly. Authelia has this scheduled for version 4.40.0 (the current release is 4.39.x). Once that lands, the config could slim down to just a URL, identical to the Atlassian experience. No mcp-remote, no --static-oauth-client-info, no manual client registration.

Wrapping Up

If you’ve got an OIDC provider running (Authelia, Keycloak, Authentik, whatever), this is a very achievable project. The pattern is straightforward: nginx as a gateway that serves OAuth metadata and validates tokens, your MCP server unchanged behind it, mcp-remote on the client side handling the flow.

The config surface is small. The moving parts are well-understood. And the result is that your mcp.json stops being a secrets file.

I’m planning a longer post about the full homelab overhaul: the CI/CD pipeline, the migration from Portainer, getting Authelia working after years of failed attempts. Stay tuned for that.

In the meantime, what MCP servers are you running that could use proper auth? And if you’ve wired up something similar with Keycloak or Authentik, I’d love to hear how your setup differs.
